| MOQ: | 1pieces |
| Price: | Contact us |
| Standard Packaging: | Original packaging box+Based on customer needs |
| Delivery Period: | 2-7 working days |
| Payment Method: | L/C, D/A, D/P, T/T, Western Union |
| Supply Capacity: | /pieces >=2 pieces |
| Chipset |
Intel® C610 Series Chipset Intel® E5-2600v3 Processor Family Intel® E5-2600v4 Processor Family |
| On System Management Chipset |
HPE iLO (Firmware HPE iLO4 2.0) 4GB NAND NOTE: Read and learn more in the iLO QuickSpecs. |
| RAM |
Type: HPE SmartMemory DDR4 Registered (RDIMM), Load Reduced (LRDIMM) or Persistent Memory (NVDIMM)
DIMM Slots Available 24 (12 DIMM slots per processor, 4 channels per processor, 3 DIMMs per channel)
Maximum Capacity (LRDIMM) 3TB (24 x 128GB LRDIMM @2400MHz)*
Maximum Capacity (RDIMM) 768GB (24 x 32GB RDIMM @2400MHz)
Maximum Capacity (NVDIMM) 128GB (16 x 8GB NVDIMM)*
NVDIMM support only with the E5-2600v4 processors, and RDIMMs only • Note mixing of 2133 and 2400MHz memory is not supported • Note mixing of RDIMM and LRDIMM memory is not supported • Note the 128GB LRDIMM may not be mixed with other DIMM capacities/types |
| Memory Protection |
Advanced ECC Advanced ECC uses single device data correction to detect and correct single and all multibit error that occurs within a single DRAM chip.
Online Spare Memory online spare mode detects a rank that is degrading and switches operation to the spare rank. |
| Expansion | |
| Storage Controller | |
| Internal Storage Devices | |
| Power Supply |
HPE 500W Flex Slot Platinum Hot Plug Power Supply NOTE: Available in 94% efficiency. HPE 800W Flex Slot Platinum Hot Plug Power Supply NOTE: Available in 94% and 96% efficiency NOTE: Also available in -48VDC and 227VAC/380VDC power inputs. HPE 1400W Flex Slot Platinum Plus Hot Plug Power Supply |
| Interfaces | |
| Standard Features |
Operating Systems and Virtualization Software Support for ProLiant Servers: Microsoft Windows Server Canonical Ubuntu Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Oracle Solaris VMware Citrix XenServer ClearOS |
1 Bay 1
2 Bay 2
3 Bay 3, fixed drive bay
4 Front USB 3.0 connector
5 Serial label pull tab
|
|
